Pioneer® Diamante Pro Series 24,000 BTU 19 SEER2 Ductless Mini-Split Air Conditioner Inverter+ Heat Pump Full Set 230V with 16 Ft. Kit

Name: Pioneer® Diamante Pro Series 24,000 BTU 19 SEER2 Ductless Mini-Split Air Conditioner Inverter+ Heat Pump Full Set 230V with 16 Ft. Kit
Brand: Pioneer
SKU: CP-Pioneer-WYT024GLFI19RL
Price: 3265.99 CAD
Availability: InStock

Item ID: 7425115127115

In Stock

$3265.99 ~~$3591.99~~

Add to Wishlist

Auto-Reorder — never run out

We’ll ship this on a schedule that suits your kitchen. Pause, change, or cancel anytime.

Ships from Calgary, AB Processing 2–3 business days · Delivery: Alberta 1–3 bd · Rest of Canada 4–7 bd

Secure SSL checkout — we accept

Pioneer

Pioneer View all Pioneer products →

Description

Elevate your indoor comfort with the Pioneer® Diamante Pro Series 24,000 BTU 19 SEER2 Ductless Mini-Split Air Conditioner Inverter+ Heat Pump Full Set 230V. Enjoy premium efficiency and comfort with high wall mounted design, variable speed DC inverter mode, and low ambient unit capability. Perfect for residential or commercial spaces, this system offers precise temperature control and energy savings

Summary

High Efficiency Diamante Pro Ductless Mini Split Heat Pump System
Cooling capacity: 24,000 BTU/H with 19 SEER2 / 10.0 EER2 efficiency
Heating capacity: 24,400 BTU/H with 8.5 HSPF2 / 3.21 COP2 efficiency
Voltage: 208~230V, 60Hz, 1Ph
High Wall Mounted Air Conditioning & Heating System
Variable Speed DC Inverter Operation Mode
Low Ambient Unit (-13°F)

What's Included

Indoor Unit
Outdoor Unit
Wireless Remote Control (with wall holder and batteries)
16 Ft. Copper Lines
16 Ft. Electrical Wire
10 Ft. Drain for indoor/outdoor
Wall Passage Sleeve
Putty for Wall Hole
Leak Guard Sealer
Wrapping Tape
Installation Manual
User’s Manual

Performance Data

Power Supply: 208~230V, 60Hz, 1Ph
Cooling Rated Capacity: 24,000 BTU/h
Cooling Capacity Range: 7,200~26,400 BTU/h
Cooling SEER2: 19.0 BTU/W.h
Cooling EER2: 10.0 BTU/W.h
Heating Rated Capacity: 24,400 BTU/h
Heating Capacity Range: 7320~26,840 BTU/h
Heating HSPF2 (Region IV/V): 8.5 / 7.0 BTU/W.h
Heating C.O.P.2 (47°F/5°F): 3.21 / 1.75 W/W
Refrigerant Type: R410A/50.1 oz.
Suitable Area: 550~1000 Sq.F

Indoor Unit Data

Part Number: WT024GLFI19HLE
Air Flow (Hi/Med/Lo): 847 / 700 / 641 CFM
Sound Level (Hi/Med/Lo): 48 / 43 / 38 dB(A)
Net Dimensions (WDH): 46-5/8 x 10-1/4 x 13-3/8 Inches
Carton Dimensions (WDH): 49-3/4 x 13-1/4 x 16-1/2 Inches
Net / Gross Weight: 37.5 / 46.3 lbs

Outdoor Unit Data

Part Number: YN024GLFI19RPE
Breaker Needed: 20A (double-pole)
Sound Level: 58.0 dB(A)
Net Dimensions (WDH): 33-1/4 x 15 x 27-1/2 Inches
Carton Dimensions (WDH): 37-3/4 x 17 x 29-1/2 Inches
Net / Gross Weight: 95.9 / 107.3 lbs

–
